Yeni Ürünler
CUAV New SKYE 2 Nano DroneCAN DLVR High Accuracy And Linearity Airspeed Sensor
Stoktan Teslim
| Ağırlık | 2085 lbs |
|---|---|
| Weight |
15g |
| Dimensions |
20 × 10 × 10 cm |
| Options |
SKYE 2 Nano * 1 piece, SKYE 2 Nano & NEO 3 GPS / Set, SKYE 2 Nano & NEO 3 Pro GPS / Set, SKYE 2 Nano & NEO 3X GPS / Set, SKYE 2 Nano & NEO 4 SE GPS / Set |
| MUC |
STM32F4 100MHz |
| Sensor |
DLVR_L10D |
| Airspeed Measurement |
0 ~ 226.8km/h |
| Error |
1% |
| ProtoCol |
DroneCan |
| Compatible Controller |
PX4/ArduPilot (CUAV/Pixhawk etc.) |
| Operating Voltage |
4.75-5.3V |
| Operating Temperature |
-20 ~ 85℃ |
| Shell Material |
Aluminum alloy |
| MCU |
32.0 × 33.4 × 18.5mm |
| Size |
32.0 × 33.4 × 18.5mm |
| Measurement speed |
0-381.6km/h |
| Accuracy |
±1%FS |
| Temperature measurement |
-20℃ to 125℃ |
| Heater |
Resistive heating*2 |
| Humidity measurement |
0-100% |
| Protection level |
IP54 |
| Flight control |
PX4/ArduPilot |
| Versiyon |
Options: SKYE 2 Nano * 1 piece ,Options: SKYE 2 Nano & NEO 3 GPS / Set ,Options: SKYE 2 Nano & NEO 3 Pro GPS / Set ,Options: SKYE 2 Nano & NEO 3X GPS / Set ,Options: SKYE 2 Nano & NEO 4 SE GPS / Set |
HEX Pixhawk Cube Orange + Flight Controller Radio System Transmitter for Quadcopters UAV
Yurtdışı Tedarik
SIYI F9P RTK Module
Stoktan Teslim
SIYI HM30 Long Range Full HD Digital Image Transmission
Yurtdışı Tedarik
GPS, GNSS & RTK
CUAV C-RTK 3 G5 Anti-Jamming Spoofing GNSS Module for Drone
Yurtdışı Tedarik
| Ağırlık | 36 lbs |
|---|---|
| Weight |
0.5 kg |
| Dimensions |
10 × 10 × 5 cm |
| Processor |
STM32H5 Arm°Cortex-M33 250 MHz |
| Hardware Channel |
789 pcs |
| Support Constellation and Band |
GPS: L1C/A 、L2C 、L2PY 、L5 、L1CGLONASS: L1CA 、L2CA 、L2P 、L3 CDMABeiDou: B11 、B1C 、B2a 、B2I 、B31 、B2bGalileo: E1 、E5a 、E5b 、E6QZSS: L1C/A 、L1 C/B 、L2C 、L5 、L6 |
| Antenna Support |
Dual Antenna (configurable single/dual antenna working mode) |
| GNSS+ Technical Kit |
AIM+(anti-jamming/ anti-spoofing),LOCK+(vibration& shock resistance),APME+(multipath mitigation),IONO+(ionospheric protection),RAIM+(integrity monitoring) |
| Support Service |
Galileo HAS High-Precision Service (look-ahead function, enabled upon software update), Galileo OSNMA Service |
| Raw Data Output |
Support/ TF Card Recoding |
| Positioning Accuracy |
Standalone Accuracy: Horizontal 1.2 m, Vertical 1.9mDGNSS Accuracy: Horizontal 0.4m, Vertical 0.7 mRTK Accuracy: Horizontal 0.6 cm+0.5 ppmVertical 1 cm+1 ppm |
| Velocity Accuracy |
3 cm/s |
| Heading Accuracy |
At 1 m antenna separation, heading accuracy: 0.15°At 5m antenna separation, heading accuracy: 0.03° |
| Max Update Rate |
20 Hz |
| RTK Initialization Time |
7s (baseline<40 km) |
| Time Accuracy Related |
PPS Resolution: 1.4 nsEvent Accuracy: <3nsCold Start Time: <35s(no Ephemeris, no Coarse Position)Hot Start Time: <10s(with Ephemeris, with Coarse Position)Re-Acquisition Time: 1s |
| Tracking and Acquisition Threshold |
Tracking Threshold: 20 dB/HzAcquisition Threshold: 30 dB/Hz |
| Built-in Magnetometer |
RM3100 |
| Measurement Range |
±1100μT(wide dynamic magnetic field adaptation) |
| Resolution |
13 nT@200 Cycle Count; Detection Sensitivity 2.7 nT at 1Hz |
| Noise Level |
15nT@200 Cycle Count; Noise Floor 4pT/√ Hz(1Hz) |
| Linearity |
0.50% within ±200μT |
| Protocol |
DroneCAN |
| Communication Rate |
1 Mbit/s(CAN)8 Mbit/s(CAN FD) |
| Upgrade Support |
Support |
| Firmware |
C-RTK3 M4C |
| Data Interface |
JST GH 1.254P/TYPE-C USB |
| Size |
55.5×50×16.5 mm [Includes screw holes] |
| Operating Temperature |
-10℃~+80℃ |
| Horizontal coverage angle |
360° |
| Polarization |
Right-hand circular polarization |
| Gain(dB) |
38±2 |
| Connector type |
SMA-J |
| Antenna size |
Φ40*84.5 mm |
| Antenna weight |
36 g |
CUAV C-RTK 9Ps Positioning Module | High Precision GPS RTK GNSS Pixhawk
Yurtdışı Tedarik
| Ağırlık | 30 lbs |
|---|---|
| Tool Supplies |
Assembly Category |
| Upgrade Parts/Accessories |
GPS |
| RC Parts & Accs |
Servo Accessories |
| Size |
32*48*12mm |
| Compass |
IST8310 |
| Remote Control Peripherals/Devices |
GPS |
| Position Accuracy |
RTK:0.01m+1ppm CEPGPS:1.5m CEP;SBAS:1.0m CEP |
| RTK Surveyin-time |
RTK<60s |
| Radio Control Style |
RC Hobby |
| C-RTK 9Ps options |
Choose an optionRover unit stand comboBase unit comboRover unit stand unit and base unitcomboC-RTK 9Ps & Pixhawk V6X V2 ControllerC-RTK 9Ps & 7-Nano V2 ControllerClear |
| Receiver |
184 channelZED-F9P(ublox) |
| GNSS |
GPS、BDS、GALILEO、GLONASS |
| Concurrent GNSS |
4 |
| GNSS Bands |
GPS-L1C/A,GPS-L2C,GLONASS-L10F,GLONASS-L2OF,GALILEO-E1B/C,GALILEO-E5b,BDS-B11,BDS-B2I,QZSS-L1CIA,QZSS-L2C, |
| Nav.update rate |
RTK20Hz; RAW25Hz; PVT25Hz (The maximum limit is related to the concurrency setting) |
| Convergence Time |
RTK<60s |
| Acquisition |
Cold start<24sHot start<1s |
| Sensitivity |
Tracking and nav-167dBmCold start-148 dBmHot start-157 dBmReacquisition -160 dBm |
| Anti-jamming |
Active CW detection and removal, Onboard band pass filter |
| Anti-spoofing |
Advanced anti-spoofing algorithms |
| Antenna Gain |
Rover:2dBi Base:5dBi |
| PPK |
Not Support |
| GPS Heading |
Support(requirestwo C-RTK9Ps);heading accuracy:0.4edg(reference value) |
| Base/Rover Role Swap |
Support |
| UART |
2 UART |
| USB |
1 |
| Protocols |
NMEA、UBX binary、RTCM 3.x |
| Operating voltage |
4.5~6V |
| Operating Temperature |
-40～85℃ |
| Weight |
30g(Module Only) |
| Versiyon |
C-Rtk-9Ps-Options: Rover unit stand combo ,C-Rtk-9Ps-Options: Base unit combo ,C-Rtk-9Ps-Options: Rover unit stand unit and base unitcombo ,C-Rtk-9Ps-Options: C-RTK 9Ps & Pixhawk V6X V2 Controller ,C-Rtk-9Ps-Options: C-RTK 9Ps & 7-Nano V2 Controller |
CUAV High Precision RM3100 Magnetic C-Compass External Compass For Pixhawk And PX4
Yurtdışı Tedarik
| Weight |
13g |
|---|---|
| Dimensions |
20 × 10 × 10 cm |
| C-Compass Options |
C-Compass * 3 Pcs, C-Compass & NEO 3 GPS / Set, C-Compass & NEO 3 Pro GPS / Set, C-Compass & NEO 3X GPS / Set |
| Sensor |
RM3100 |
| MCU |
STM32F412 |
| Software Architecture |
CUAV M4C |
| Protocol |
DroneCan/UAVCAN |
| Accuracy |
0.25° (effective value) |
| Repetition Accuracy |
0.05° |
| Controller Type |
PX4/ArduPilot (CUAV/Pixhawk etc.) |
| Operating Voltage |
4.75-5.3V |
| Operating Temperature |
-20～80℃ |
| Communication Rate |
2Mb |
| Refresh Rate |
80Hz |
| Noise |
15nT |
| Resolution |
0.01° |
| Sensitivity |
13nT |
| Range |
-800 μTto+800 μT |
| Interface |
GHR-04V-S |
| Operating Humidity |
5%～95%(non-condensing) |
| Casing Material |
Aluminum alloy |
| Size |
31.5×31.0×14.0mm |
| Versiyon |
C-Compass-Options: C-Compass * 3 Pcs ,C-Compass-Options: C-Compass & NEO 3 GPS / Set ,C-Compass-Options: C-Compass & NEO 3 Pro GPS / Set ,C-Compass-Options: C-Compass & NEO 3X GPS / Set |
CUAV IST8 External Compass of GPS Module | PX4 Geomagnetic Sensor IST8310
Yurtdışı Tedarik
| Ağırlık | 0.5 lbs |
|---|---|
| Weight |
0.5 kg |
| Dimensions |
20 × 10 × 10 cm |
| IST8 Compass Options |
IST8 Compass V5+ version * 3 Pcs, IST8 & NEO 3 GPS / Set, IST8 & NEO 3 Pro GPS / Set, IST8 & NEO 3X GPS / Set |
| Rated voltage |
10 ~ 60V（3 ~ 14S Lipo) |
| Current(MAX) |
60A |
| Current Accuracy |
±0.2A |
| Voltage Accuracy |
±0.1V |
| 12V OUT |
4A |
| 5V OUT |
2A |
| FC power |
5A |
| Battery |
XT60 |
| 12V OUT5V OUTFC Power |
GH1.25 |
| Versiyon |
Ist8-Compass-Options: IST8 Compass V5+ version * 3 Pcs ,Ist8-Compass-Options: IST8 & NEO 3 GPS / Set ,Ist8-Compass-Options: IST8 & NEO 3 Pro GPS / Set ,Ist8-Compass-Options: IST8 & NEO 3X GPS / Set |
