CUAV 7 Nano V2 Upgrade Small Size Controller for FPV Drone
Yurtdışı Tedarik
| Weight |
33g |
|---|---|
| Dimensions |
10 × 10 × 5 cm |
| Processor |
STM32H753(Arm Cortex -M7,480MHz, 2MB FLASH) |
| Acce&Gyro |
IIM-42652/BMI088 |
| Compass |
IST8310 |
| UART |
5 |
| 12C |
3 |
| PWM Output |
14 |
| PWM Level |
3.3V/5V(8 CH) |
| RC IN |
1 |
| RSSI |
Support |
| Size |
30.5×25.5×31.8mm |
| Barometer |
ICP-20100/BMP581 |
| I2C |
3 |
| PWM OUT |
14 (Configurable for 3.3V / 5V) |
| CAN BUS |
2 |
| Power IN |
1 |
| Safety Switch |
1 |
| GPS 2 |
1 |
| ADC |
ADC3.3 & ADC6.6 |
| Debug |
FMU Debug |
| USB |
Type-C |
| Ethernet |
1 |
| Rated Voltage |
4.5 ~ 5.5 V |
| USB Voltage |
4.75 ~ 5.25 V |
| Servo Voltage |
0 ~ 10 V |
| Working Temp |
-20 ~ 85 ℃ |
| Humidity |
5% ~ 95%（Does not condense） |
| Detection Current(MAX) |
79.2 A |
| BEC OUT |
5.3V / 4A |
| Voltage and Current Accuracy |
±0.2V / 0.5A |
| Splitter |
Divided into six |
| Interfaces |
XT60 / GH1.25 6Pin |
| Main processor |
STM32H753 |
| Power |
1 |
| GPS&Safety |
1 |
| GPS2 |
1 |
| TELEM |
2 |
| TF card slot |
1 |
| Power Module |
7-Nano PDB |
CUAV 7-Nano V2 Open Source Controller Drone Accessories Kits
Yurtdışı Tedarik
| Weight |
33g |
|---|---|
| Dimensions |
10 × 10 × 5 cm |
| Processor |
STM32H753(Arm Cortex -M7,480MHz, 2MB FLASH) |
| Acce&Gyro |
IIM-42652/BMI088 |
| Compass |
IST8310 |
| UART |
5 |
| 12C |
3 |
| PWM Output |
14 |
| PWM Level |
3.3V/5V(8 CH) |
| RC IN |
1 |
| RSSI |
Support |
| Size |
30.5×25.5×31.8mm |
| Accessories Kit Options |
Choose an option7-Nano V2 Controller Standard7-Nano V2 Controller with PDB Power Module7-Nano V2 Controller with NEO 3X GNSS Module7-Nano V2 Controller with NEO 3 Pro GNSS Module7-Nano V2 Controller with NEO 4 SE GNSS Module7-Nano V2 Controller with NEO 4 Nano GNSS Module7-Nano V2 Controller with C-RTK 9 Ps(Rover Unit, Base Unit, Stand Combo)7-Nano V2 Controller with C-RTK 9 Ps(Base Unit) & C-RTK 2HP(Rover Unit)Clear |
| Barometer |
ICP-20100/BMP581 |
| I2C |
3 |
| PWM OUT |
14 (Configurable for 3.3V / 5V) |
| CAN BUS |
2 |
| Power IN |
1 |
| Safety Switch |
1 |
| GPS 2 |
1 |
| ADC |
ADC3.3 & ADC6.6 |
| Debug |
FMU Debug |
| USB |
Type-C |
| Ethernet |
1 |
| Rated Voltage |
4.5 ~ 5.5 V |
| USB Voltage |
4.75 ~ 5.25 V |
| Servo Voltage |
0 ~ 10 V |
| Working Temp |
-20 ~ 85 ℃ |
| Humidity |
5% ~ 95%（Does not condense） |
| Detection Current(MAX) |
79.2 A |
| BEC OUT |
5.3V / 4A |
| Voltage and Current Accuracy |
±0.2V / 0.5A |
| Splitter |
Divided into six |
| Interfaces |
XT60 / GH1.25 6Pin |
| Main processor |
STM32H753 |
| Power |
1 |
| GPS&Safety |
1 |
| GPS2 |
1 |
| TELEM |
2 |
| TF card slot |
1 |
| Power Module |
7-Nano PDB |
| Versiyon |
Accessories-Kit-Options: 7-Nano V2 Controller Standard ,Accessories-Kit-Options: 7-Nano V2 Controller with PDB Power Module ,Accessories-Kit-Options: 7-Nano V2 Controller with NEO 3X GNSS Module ,Accessories-Kit-Options: 7-Nano V2 Controller with NEO 3 Pro GNSS Module ,Accessories-Kit-Options: 7-Nano V2 Controller with NEO 4 SE GNSS Module ,Accessories-Kit-Options: 7-Nano V2 Controller with NEO 4 Nano GNSS Module ,Accessories-Kit-Options: 7-Nano V2 Controller with C-RTK 9 Ps(Rover Unit, Base Unit, Stand Combo) ,Accessories-Kit-Options: 7-Nano V2 Controller with C-RTK 9 Ps(Base Unit) & C-RTK 2HP(Rover Unit) |
CUAV C-RID Drone Remote ID Broadcast Module
Yurtdışı Tedarik
| Ağırlık | 475.2 lbs |
|---|---|
| Weight |
0.0155 kg |
| Dimensions |
30 × 38 × 10 cm |
| C-RID Remote ID Options |
C-RID * 3 Pcs, C-RID & NEO 3 GPS / Set, C-RID & NEO 3 Pro GPS / Set, C-RID & NEO 3X GPS / Set |
| Processor |
Xtensa32-bit LX7dual-coreprocessor |
| Transmit Power |
20dBm |
| Communication Frequency |
2.4GHz |
| Communication Mode |
Wi-Fi or Bluetooth Broadcast |
| Range |
>300m |
| Protocol |
DroneCAN/ UART(MAVLink) |
| Firmware |
ArduRemotelD (Support OTA Online Upgrade) |
| Ports |
1xCAN （4-pinGH1.25）1xUART（4-pinGH1.25)1×ANT(MMCX) |
| Shell Material |
Aviation Aluminum |
| Operating Voltage |
4.7~5.2V |
| LED (main) Status |
Off:Not connected or not workingConstant Red:Configuration is not completed(disarming conditionsarenotmet)Constant Green:Configuration is successful,unlockable |
| Size |
Main: 24×38x10mmIncluding Fixing Hole: 38x38x10mm |
| Versiyon |
C-Rid-Remote-Id-Options: C-RID * 3 Pcs ,C-Rid-Remote-Id-Options: C-RID & NEO 3 GPS / Set ,C-Rid-Remote-Id-Options: C-RID & NEO 3 Pro GPS / Set ,C-Rid-Remote-Id-Options: C-RID & NEO 3X GPS / Set |
CUAV C-RTK 3 G5 Anti-Jamming Spoofing GNSS Module for Drone
Yurtdışı Tedarik
| Ağırlık | 36 lbs |
|---|---|
| Weight |
0.5 kg |
| Dimensions |
10 × 10 × 5 cm |
| Processor |
STM32H5 Arm°Cortex-M33 250 MHz |
| Hardware Channel |
789 pcs |
| Support Constellation and Band |
GPS: L1C/A 、L2C 、L2PY 、L5 、L1CGLONASS: L1CA 、L2CA 、L2P 、L3 CDMABeiDou: B11 、B1C 、B2a 、B2I 、B31 、B2bGalileo: E1 、E5a 、E5b 、E6QZSS: L1C/A 、L1 C/B 、L2C 、L5 、L6 |
| Antenna Support |
Dual Antenna (configurable single/dual antenna working mode) |
| GNSS+ Technical Kit |
AIM+(anti-jamming/ anti-spoofing),LOCK+(vibration& shock resistance),APME+(multipath mitigation),IONO+(ionospheric protection),RAIM+(integrity monitoring) |
| Support Service |
Galileo HAS High-Precision Service (look-ahead function, enabled upon software update), Galileo OSNMA Service |
| Raw Data Output |
Support/ TF Card Recoding |
| Positioning Accuracy |
Standalone Accuracy: Horizontal 1.2 m, Vertical 1.9mDGNSS Accuracy: Horizontal 0.4m, Vertical 0.7 mRTK Accuracy: Horizontal 0.6 cm+0.5 ppmVertical 1 cm+1 ppm |
| Velocity Accuracy |
3 cm/s |
| Heading Accuracy |
At 1 m antenna separation, heading accuracy: 0.15°At 5m antenna separation, heading accuracy: 0.03° |
| Max Update Rate |
20 Hz |
| RTK Initialization Time |
7s (baseline<40 km) |
| Time Accuracy Related |
PPS Resolution: 1.4 nsEvent Accuracy: <3nsCold Start Time: <35s(no Ephemeris, no Coarse Position)Hot Start Time: <10s(with Ephemeris, with Coarse Position)Re-Acquisition Time: 1s |
| Tracking and Acquisition Threshold |
Tracking Threshold: 20 dB/HzAcquisition Threshold: 30 dB/Hz |
| Built-in Magnetometer |
RM3100 |
| Measurement Range |
±1100μT(wide dynamic magnetic field adaptation) |
| Resolution |
13 nT@200 Cycle Count; Detection Sensitivity 2.7 nT at 1Hz |
| Noise Level |
15nT@200 Cycle Count; Noise Floor 4pT/√ Hz(1Hz) |
| Linearity |
0.50% within ±200μT |
| Protocol |
DroneCAN |
| Communication Rate |
1 Mbit/s(CAN)8 Mbit/s(CAN FD) |
| Upgrade Support |
Support |
| Firmware |
C-RTK3 M4C |
| Data Interface |
JST GH 1.254P/TYPE-C USB |
| Size |
55.5×50×16.5 mm [Includes screw holes] |
| Operating Temperature |
-10℃~+80℃ |
| Horizontal coverage angle |
360° |
| Polarization |
Right-hand circular polarization |
| Gain(dB) |
38±2 |
| Connector type |
SMA-J |
| Antenna size |
Φ40*84.5 mm |
| Antenna weight |
36 g |
CUAV C-RTK 9Ps Positioning Module | High Precision GPS RTK GNSS Pixhawk
Yurtdışı Tedarik
| Ağırlık | 30 lbs |
|---|---|
| Tool Supplies |
Assembly Category |
| Upgrade Parts/Accessories |
GPS |
| RC Parts & Accs |
Servo Accessories |
| Size |
32*48*12mm |
| Compass |
IST8310 |
| Remote Control Peripherals/Devices |
GPS |
| Position Accuracy |
RTK:0.01m+1ppm CEPGPS:1.5m CEP;SBAS:1.0m CEP |
| RTK Surveyin-time |
RTK<60s |
| Radio Control Style |
RC Hobby |
| C-RTK 9Ps options |
Choose an optionRover unit stand comboBase unit comboRover unit stand unit and base unitcomboC-RTK 9Ps & Pixhawk V6X V2 ControllerC-RTK 9Ps & 7-Nano V2 ControllerClear |
| Receiver |
184 channelZED-F9P(ublox) |
| GNSS |
GPS、BDS、GALILEO、GLONASS |
| Concurrent GNSS |
4 |
| GNSS Bands |
GPS-L1C/A,GPS-L2C,GLONASS-L10F,GLONASS-L2OF,GALILEO-E1B/C,GALILEO-E5b,BDS-B11,BDS-B2I,QZSS-L1CIA,QZSS-L2C, |
| Nav.update rate |
RTK20Hz; RAW25Hz; PVT25Hz (The maximum limit is related to the concurrency setting) |
| Convergence Time |
RTK<60s |
| Acquisition |
Cold start<24sHot start<1s |
| Sensitivity |
Tracking and nav-167dBmCold start-148 dBmHot start-157 dBmReacquisition -160 dBm |
| Anti-jamming |
Active CW detection and removal, Onboard band pass filter |
| Anti-spoofing |
Advanced anti-spoofing algorithms |
| Antenna Gain |
Rover:2dBi Base:5dBi |
| PPK |
Not Support |
| GPS Heading |
Support(requirestwo C-RTK9Ps);heading accuracy:0.4edg(reference value) |
| Base/Rover Role Swap |
Support |
| UART |
2 UART |
| USB |
1 |
| Protocols |
NMEA、UBX binary、RTCM 3.x |
| Operating voltage |
4.5~6V |
| Operating Temperature |
-40～85℃ |
| Weight |
30g(Module Only) |
| Versiyon |
C-Rtk-9Ps-Options: Rover unit stand combo ,C-Rtk-9Ps-Options: Base unit combo ,C-Rtk-9Ps-Options: Rover unit stand unit and base unitcombo ,C-Rtk-9Ps-Options: C-RTK 9Ps & Pixhawk V6X V2 Controller ,C-Rtk-9Ps-Options: C-RTK 9Ps & 7-Nano V2 Controller |
CUAV C-RTK Expansion Module | USL Extension Integrator Safety Switch Buzzer LED Indicator For USB C-RTK Extension
Yurtdışı Tedarik
CUAV CAN Babel Dual-function USB CAN Bus Adapter
Yurtdışı Tedarik
CUAV CAN PDB Multifunctional Drone Controller Baseboard
Yurtdışı Tedarik
| Ağırlık | 200 lbs |
|---|---|
| Set |
CAN PDB Only, CAN PDB With V5+ Core, CAN PDB With X7+ Core, CAN PDB With X7+ Pro Core |
| Material |
Metal |
| Upgrade Parts/Accessories |
Flight controller |
| RC Parts & Accs |
Speed controller |
| Size |
89*42.5*33mm |
| Use |
Vehicles & Remote Control Toys |
| Technical parameters |
KV1100 |
| Remote Control Peripherals/Devices |
Remote Controller |
| Four-wheel Drive Attributes |
Battery |
| MCU |
STM32F412(32 Bit Arm® Cortex®-M4, 100MHz, 512KB FLASH, 256KB RAM) |
| Operating Voltage |
14 ~ 62V（4 ~ 15S Lipo) |
| Detection Current Range |
0 ~ 110A |
| Output Power(MAX) |
6000W（last 120s） |
| Stable Output Power(MAX) |
5500W |
| Core |
V5+ / X7+ / X7+ Pro CORE |
| Frame Type |
Plane/VTOL/Copter/Heli/Rover/Sub |
| Controller Firmware |
ArduPilot 4.0.0 and above firmwarePX4 1.11.0 and above firmware |
| Operating Temperature |
-20 ~ 100℃ |
| V_OUT |
5V(default)/7.4V/8.2V(4A） |
| Servo VCC |
5V(default)/7.4V/8.2V(8A） |
| 12V OUT |
4A(max) |
| USB |
1 |
| UART1 |
5(GPS/UART4/TELEM1/TELEM2/DEBUG) |
| CAN |
2 |
| I2C |
3 |
| SBUS/DSM IN |
1 |
| PPM IN |
1 |
| Servo |
14 |
| ADC3.3 |
1 |
| ADC6.6 |
1 |
| SBUS Outs |
1(This interface is invalid when using X7+/X7+pro core) |
| RSSI |
3.3V(Analog input) |
| DSU7 |
1 |
| Weight |
200g (including cable) |
| Wire Length |
30cm |
| Versiyon |
Set: CAN PDB Only ,Set: CAN PDB With V5+ Core ,Set: CAN PDB With X7+ Core ,Set: CAN PDB With X7+ Pro Core |
CUAV CAN PMU High Precision Power Detection Unit For unmanned Hardware
Yurtdışı Tedarik
| Ağırlık | 20100 lbs |
|---|---|
| Weight |
0.15 kg |
| Dimensions |
4.6 × 3.8 × 2.2 cm |
| Processor |
STM32F412 100Mhz 512K flash 256K RAM |
| Voltage Input |
6 ~ 62V(2 ~ 15S) |
| Max Current |
110A |
| Voltage Accuracy |
±0.05V |
| Current Accuracy |
±0.1A |
| Resolution |
0.01A/V |
| Max Output Power |
6000W/90s |
| Max Stable Power |
5000W |
| Protocol |
UAVCAN |
| Operating Temp |
-20 ~ 100 ℃ |
| Power Port Output |
5.4V/5A |
| Firmware Upgrade |
Support |
| Calibration |
Factory calibration |
| Interface Type |
IN/OUT: XT90(Cable）/Amass 8.0(Module）Power: 5025850670CAN: GHR-04V-S |
| Size |
46.5 × 38.5 × 22.5mm |
CUAV CAN PMU Lite Power Module | Open Source Drone Hardware
Yurtdışı Tedarik
| Ağırlık | 20100 lbs |
|---|---|
| Processor |
STM32F103CEU6 |
| Input voltage |
10-62V (2-15S Lipo) |
| Maximum current |
90A |
| Voltage accuracy |
±0.15V |
| Current accuracy |
±0.2A |
| Resolution |
0.01A/V |
| Maximum output power |
4200W/90S |
| Maximum stable output power |
3600W |
| 5V regulated output |
maximum 5A, stable 4A |
| Communication protocol |
UAVCAN |
| CAN PMU Lite Options |
Choose an optionCAN PMU Lite * 2 PcsCAN PMU Lite & Pixhawk V6X V2 ControllerCAN PMU Lite & NEO 3 GPS / SetCAN PMU Lite & NEO 3 Pro GPS / SetCAN PMU Lite & NEO 3X GPS / SetClear |
| oltage accuracy |
±0.15V |
| letter of agreement |
UAVCAN |
| Operating temperature |
-20 ~ 100℃ |
| Firmware upgrade |
stand by |
| Interface Type |
IN / OUT: XT60-M / XT60-F Power/CAN: 502585-0670 Other: SM06B-GHS-TB |
| Product Size |
140mm (length) * 25mm (width) * 13mm (height) |
| APM firmware support |
1.Rover 3.5.1and above are available 2.Copter 3.7and above are available 3.Plane 3.10and above are available 4.Heli3.7and more available Copter3.6firmware users need toflash the3.7version firmware and then flash back to the 3.6 version |
| PX4 firmware support |
PX4 Pro V1.10.1 or higher |
| Versiyon |
Can-Pmu-Lite-Options: CAN PMU Lite * 2 Pcs ,Can-Pmu-Lite-Options: CAN PMU Lite & Pixhawk V6X V2 Controller ,Can-Pmu-Lite-Options: CAN PMU Lite & NEO 3 GPS / Set ,Can-Pmu-Lite-Options: CAN PMU Lite & NEO 3 Pro GPS / Set ,Can-Pmu-Lite-Options: CAN PMU Lite & NEO 3X GPS / Set |
CUAV CPDB Pro | Drone Hardware
Yurtdışı Tedarik
| Ağırlık | 35 lbs |
|---|---|
| CPDB Pro Version Options |
CPDB Pro – X7 Version * 2 Pcs, CPDB Pro – V5 Version * 2 Pcs, CPDB Pro – Pixhack Version * 2 Pcs, CPDB Pro & NEO 3 GPS / Set, CPDB Pro & NEO 3 Pro GPS / Set, CPDB Pro & NEO 3X GPS / Set |
| RC Parts & Accs |
Motor Components |
| Upgrade Parts/Accessories |
Lithium Battery |
| Remote Control Peripherals/Devices |
servos |
| Four-wheel Drive Attributes |
power board |
| Use |
Vehicles & Remote Control Toys |
| Size |
51*39*16mm |
| For Vehicle Type |
Airplanes |
| Type |
Airplane |
| Packing |
Packing |
| Radio Control Style |
RC Model |
| Rated voltage |
10 ~ 60V（3 ~ 14S Lipo) |
| Current(MAX) |
60A |
| Current Accuracy |
±0.2A |
| Voltage Accuracy |
±0.1V |
| 12V out |
4A |
| 5V out |
2A |
| FC power |
5A |
| Battery |
XT60 |
| 12V out5V outFC Power |
GH1.25 |
| Weight |
35g |
| Versiyon |
Cpdb-Pro-Version-Options: CPDB Pro – X7 Version * 2 Pcs ,Cpdb-Pro-Version-Options: CPDB Pro – V5 Version * 2 Pcs ,Cpdb-Pro-Version-Options: CPDB Pro – Pixhack Version * 2 Pcs ,Cpdb-Pro-Version-Options: CPDB Pro & NEO 3 GPS / Set ,Cpdb-Pro-Version-Options: CPDB Pro & NEO 3 Pro GPS / Set ,Cpdb-Pro-Version-Options: CPDB Pro & NEO 3X GPS / Set |
